L&T VFD

L&T VFD

Product Details:

  • Product Type MCCB
  • Application For Electric Motor Use
  • Rated Voltage 230-415 Volt (V)
  • Supply Voltage 110-440 Volt (v)
  • Color Grey
  • Weight 1-10 Kilograms (kg)
  • Supply Ability : 1 Piece Per Day
  • Click to view more
X

Price And Quantity

  • 6000 INR
  • 1 Piece

Product Specifications

  • 1-10 Kilograms (kg)
  • 110-440 Volt (v)
  • Grey
  • 230-415 Volt (V)
  • For Electric Motor Use
  • MCCB

Trade Information

  • Telegraphic Transfer (T/T), Cheque
  • 1 Piece Per Day
  • 2-3 Days
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • All India

Product Description

Compact, lightweight, easy to install, operate and service - the Cx2000 is perfectly suited for conveyors, pumps, fans and textile machinery. It handles loads up to 11 kW, and is engineered to keep your machine operating at optimum efficiency, even in the hot, humid and dusty conditions that characterise India's industrial environment.

Range:

  • Single Phase 230V - 0.1 to 2.2kW
  • Three Phase 230V - 0.2 to 11kW
  • Three Phase 415V - 0.75 to 11kW

Enclosures: IP20

Features:

  • V/F Control, Sensorless Vector Control, Slip Compensation
  • Starting Torque 150% at 3 Hz
  • Built-in Potentiometer
  • Conformal Coated PCB
  • Built-in RS485 Modbus
  • RPM Display
  • Draw Mode
  • Brake Control
  • Auto Tuning
  • Built-in PID
  • 2nd Motor Operation
  • Built-in Safety circuit
  • Built-in Braking Chopper up to 11kW

Dual rating operation:

Designed to be used for heavy and normal duty applications.

Overload capacity
  • Heavy duty operation: 150% of rated current for 60 sec
  • Normal duty operation: 110% of rated current for 60 sec

Built-in Potentiometer:

  • Possible to add reference from keypad and external signal
  • Provides external potentiometer for easier frequency control

Built-in PID:

Cx2000 has built-in PID which saves use of external PID

2nd Motor Operation:

  • Single AC Drive can maintain 2 motor parameters connected to 2 different loads with different Accel / Deccl parameter setting
  • For isolated operation of motors one VFD can be used in place of 2

Easy Maintenance:

Tool-less replacement of Cooling Fan.

Built-in Brake Chopper:

Built-in brake chopper which saves panel space.
